Milk
Beverages
Bubbles
White wine
Red wine
Fruit and vegetables
Coffee
- Ventilated
- Automatic / Electric (ext UC) / Automatic / Hot Gas (int UC) / Automatic / Natural (ext UC)
- R290 (UC int.) / R452A
- N. 4 / 30 °C / U.R. 55%
- Hermetic
- -20°C / +6°C
- 230 V / 1 ph / 50 Hz / 230 V / 1 ph / 60 Hz (opt.)
- B
Sleek and modern designfor superb refrigeration solutions
Customization
All visible components can be customized using Ciam’s range of materials, which includes a wide selection of stoneware, acrylics, quartz composites, natural stones, epoxy powder-coated sheets, electroplated sheets, brass, and wood.
Micro-Hinges
The design-inspired micro hinges have a load capacity of 30 kg and are adjustable in three sizes to ensure perfect door alignment.
Compact Version
A stylistic variant particularly popular with architects and designers is the Compact version, which includes an aluminum groove profile and eliminates all visible handles.
Design Focus
Aesthetic continuity
Refrigerated and ambient bases can be combined in aesthetic continuity to meet any professional and functional need.
Stainless steel doors
Stainless steel doors are insulated and suitable for both positive and negative temperature. The standard finish is polished stainless steel, but they can be powder coated in RAL colors upon request. The removable magnetic gasket ensures a tight seal on the refrigerated module and makes it easy to open.
Glazed doors
Refrigerated modules can be configured with triple-glazed thermal doors. Standard screen printing is black, but custom RAL colors or the unique mirror finish can be requested.
Stainless steel drawers
Stainless steel drawers are available as optional equipment in different heights and depths, and are compatible with Bar and Gastronomy series modules. The drawers are telescopic with full extension.
Glazed drawers
Drawer cabinets can also be made in a thermal version with triple-glazing. Standard screen printing is black, but custom RAL colors or the unique mirror finish can be requested.
Technical compartment
Through careful design of the refrigeration unit condenser, the size of the motor compartment has been reduced to only 25 cm wide. The condensing unit is equipped with an easily removable filter, which simplifies cleaning, preventing breakage and preserving compressor life.
Cell modules
The cell modules are monolithic, with 60 mm insulation made of environmentally friendly water-based polyurethane. The inner edges are rounded, and the cladding is AISI 304 stainless steel. The front wall of the cell module incorporates a plastic magnetic profile, which ensures a perfect closure and optimal fit with the doors.
Stainless steel tops
Steel countertops can be equipped with a wide selection of weld-on sinks and perimeter lowering, including inside the refrigerated compartment (available only for H750 and H850 versions with depths of 660 and 750 mm).
Feet
The base is composed of a stainless steel profile and has height-adjustable feet, with a size range from 80 mm to 200 mm.
Kit of casters
Casters can be applied instead of feet, upon request.
Kickplate
A stainless steel profile can be applied to cover the feet upon request.
Removable slides for ice cream tubs
Low-temperature modules can be equipped with removable telescopic guides for ice cream pans.
Cutting-edge technologyat the service of your spaces
Ventilated refrigeration
The ventilated refrigerated cell modules have the compact refrigeration system with high efficiency for both positive and negative temperature. Plug-in versions have the tropicalized class 4 condensing unit and use the eco-friendly gas R290. Defrosting is automatic at hot gas with integrated condensate evaporation tray. In negative-temperature modules with external motor, defrosting is electric.
Static refrigeration
Static refrigerated cell modules are equipped with a coil system built into the inner walls. In positive-temperature versions, the coil is embedded in the back, while in negative-temperature versions, it is also present in the sides and ceiling. Plug-in versions have a tropicalized class 4 condensing unit and use the environmentally friendly gas R290. Hot gas defrosting is automatic, with an integrated condensate evaporation tray.
Meat dry-aging
The ventilated refrigerated meat dry-aging modules are equipped with the Touch-Pro control unit, which includes preset dry-aging recipes and offers the possibility of customizing them or creating new ones. All desired humidity and temperature values inside the refrigerated cell can be set and programmed. This type of system is compatible with the size of the Gastronomy series.
Technical Features
Electronic fans
The compact high-efficiency refrigeration system is equipped with low-power electronic fans.
R290 internal CU
Plug-in modules have tropicalized Class 4 condensing unit with integrated condensate evaporation pan and use eco-friendly R290 gas.
Humidity control
In the pastry series modules, it is possible to set the desired humidity values inside the refrigerated cell.
Thermostatic valve
Systems with external engine have thermostatic valve as standard.
Electronic thermostatic valve
Upon request, the refrigeration system can be equipped with an electronic thermostatic valve, which is particularly useful for modules with an external motor or connection to a central refrigeration unit.
Hot gas defrosting
Refrigerated modules with R290 internal condensing unit are equipped with hot gas defrost as standard.
Electric defrosting
Ventilated low-temperature refrigerated modules with external motor are equipped with electric defrost as standard.
Condensate evaporator pan
Plug-in cell modules are equipped with a condensate evaporator pan as standard. Upon request, modules with an external motor can also be equipped with this tray by inserting it directly into the technical compartment. This facilitates maintenance operations and allows the cell module to be placed directly on the ground, without feet.
Lighting
Upon request, a micro-lamp with low-consumption 3000°K no-spot LED strip lighting can be installed inside the cell, with automatic switching on when the door is opened.
Sink utilities channeling
For ventilated refrigerated modules, the condensate water is channeled directly into the technical compartment built into the back panel. Here, the water can evaporate via a condensate evaporator pan or be connected to the room drainage system. Modules with static refrigeration, on the other hand, have a condensate drain with a classic drain in the bottom of the tank.
Plumbing utility channelization
For sinks installed inside the cells, the plumbing utility channelization system is concealed and well integrated into the back panel.
Touch Panel
All refrigerated modules come standard with an elegant touch control panel.
Ciam Connect
With Ciam Connect, the refrigerator is online and from the cloud you can manage all functions in addition to the alarm reporting and fault prevention service.
QR Code
Inside the refrigerator there is a product label with a QR code, which allows users to download operation and maintenance manuals and other technical content related to the product.
